Small COFDM AV/BNC/HDMI/SDI Receiver SFGT-DR2000
Utilizing the latest COFDM modulation and narrow bandwidth as its core, SFGT-DR2000 video receiver can match various microwave wireless signal receiving, such as drone video downlink, long-range vehicle surveillance video, body-worn camera video decoding.
Contact
Product Introduction

SFGT-DR2000 is a portable mini wireless AV/HDMI/SDI receiver. It automatically configures COFDM and decoder parameters for the received signals and supports resolutions from 480i to 1080i/60 in both MPEG2 and H.264 compression, with HDMI and BNC outputs.

Utilizing the latest COFDM modulation and narrow bandwidth as its core, the SFGT-DR2000 video receiver can match various microwave wireless signal receiving, such as drone video downlink, long-range vehicle surveillance video, body-worn camera video decoding.



Product Features

  1. Latest COFDM modulation

  2. High receiving sensitivity up to -105db at 2M

  3. Strong anti-interference and anti-jamming ability in NLOS environment

  4. Small size and compact design, fit for outdoor mission



Product Parameters

Model

SFGT-DR2000

Sensitivity

<- 105dBm

Receiving Frequency

300Mhz-4.4Ghz (Customizable)

RF Interface

N(F)

Video Format

H.264/ H.265

Power Supply

DC12V

Modulation

COFDM, 2K

Video Output

AV/BNC/HDMI/RJ45(Customizable)

Audio Output

Analog stereo left and right channels

FEC

1 / 2

Guard Interval

1 / 32

Video Output

1 line PAL / NTSC analog video

Resolution

1920*1080, 720*576

Lines Of Horizontal:

625 /525

Operating Temperature

-30~55°C

Size

140*170*30mm

Weight

1.6Kg
