SFGT-MS1010MP IP MESH is designed specifically for executing tactical soldier-borne wireless video, voice, and network communication missions. It can quickly establish a reliable wireless link for the user in complex environments, and it can interconnect and interoperate with other SFGT IP MESH products, such as SFGT-MS0202HH, MS0202SCSP, and other products with the same architecture.
This system is suitable for use in military and emergency response applications.
1. Adopts FPGA architecture, multi-waveform, ultra-wideband, high-speed frequency hopping technology
2. Strong function of anti-interference
3. All nodes can act as information acquisition node relay node or information output node at the same time
Transfer characteristic | |
Frequency | 300MHz-8GHz(Customizable) |
RF power | 37-40dBm (Adjustable) |
Modulation | COFDM/LTE/FPGA |
Constellation | BPSK/QPSK/16QAM/64QAM (self- adaption） |
FEC | 1/2, 2/3, 3/4, 5/6（optional） |
RF bandwidth | 1/2/5/10/20/40MHz (Customizable) |
Sensitivity | -102dBm@1.4MHz |
Transfer rate | Peak 40Mbps@30MHz |
Distance | 15-20KM LOS, 5-8km NLOS |
Network capability | 32/ 64/128 nodes (Customizable) |
Working voltage | DC22-28V |
Working current | 2A(classic) |
Data characteristic | |
Video input | IP camera/HDMI/AV(Customizable) |
Audio input | MIC/PTT |
Encryption mode | AES128/256 or user defined |
Built in module | WIFI/GPS/Beidou |
Physical characteristic | |
Protect grade | IP65 |
Operating temperature | -30℃~+55℃ |
Storage environment | -40℃~+70℃ |
Weight | 4.3kg (with battery) |
Dimension | 260*180*75mm |
