250km FPGA UAV Telemetry Video Data Link SFGT-HF0808UF
The SFGT-HF0808UF device adopts FPGA architecture, multi-wavelength, ultra-wideband, high-speed frequency hopping technology as its core. This allows a group of mesh nodes to form a seamless and highly secure private network, even in line-of-sight (LOS) or non-line-of-sight (NLOS) conditions, under fast-moving circumstances.
Contact
Product Introduction

The SFGT-HF0808UF device adopts FPGA architecture, multi-wavelength, ultra-wideband, high-speed frequency hopping technology as its core. This allows a group of mesh nodes to form a seamless and highly secure private network, even in line-of-sight (LOS) or non-line-of-sight (NLOS) conditions, under fast-moving circumstances.



With its ultra-wide and robust frequency hopping, point frequency characteristics, the device can hop 1200 times per second. This makes it well-suited for UAVs to achieve anti-interference capabilities in complex warfare environments. This feature ensures that telemetry data control and remote video transmissions are more stable and secure.



Product Features

1. Low delay video & data transmission

2. 128/256-bit AES encryption

3. Swarmable networking, Strong anti-interference ability

4. Long-distance data and video transmission in areas with rough terrain



Product Specification


Transmission feature

Transmitting power

5-8W (Customizable)

Frequency

300Mhz-8Ghz

(Customizable)

Bandwidth

1/2/5/10/20 (Adjustable)

Nodes

32/64/128 nodes

(Customizable)

Transmission range

250KM (Air to Ground)

Power supply

Operation voltage

DC14-24V

Current

1.6A

Signal feature

Interface

SMA/RJ45/TTL

(Customizable)

Sensitivity

-104dBm

Baud rate

115200bps(Adjustable)

RF connector

SMA type

Encryption

AES128/AES256/User Defined

Physical feature

Operating temperature

-30°C ~ +55°C

Storage temperature

-40°C ~ +70°C

Size

78mm*144mm*53mm (Customizable)

Weight

Aprx. 800g (Customizable)
