4 Channels COFDM Receiver SG-CH4
Code: SG-CH4
Original: 0.00
Detail


Name

COFDM 4 in one Wireless Portable Monitor

Model


Special Features

1.Standar COFDM reception,double aerial receiving;

2.Special designed with 17inch LCD monitor DVR;

3.Four channel Video audio recording and monitoring;

4.Internal 60G/120/G/1000G SSD memory;

5.Support 4 channel transmitters video surveillance

6.Can control operation system by using an external professional keyboard




specification

Frequency :300-4400MHz (optional)
Memory: 60G/120G//1000G, 4 channel 48hours recording
LCD monitor: 17inch
RF Level Input: -92dBm~-20dBm / -105dBm~-20dBm
RF Interface: N(F)

Video output: HDMI, BNC

Audio output: Stereo audio L-R output
Modulation :COFDM, 2K
Power supply:AC220V / DC12V
Bandwidth:2/2.5/4/8MHz(adjustable)
Constellation:QPSK,16QAM,64QAM(optional),QPSK/16QAM/64QAM @ 6/7/8MHz
FEC:1/2,2/3,3/4,5/6,7/8(optional)
Guard Interval :1/32,1/16,1/8,1/4 (optional)
Video format : PAL/NTSC
Video Decoding: H.264
Resolution :1920*1080, 720P/i
Lines of horizontal :625 or 525 Line
Encryption :AES128/256bits/ AES user-defined password
Operating temperature:-30~70° C
Built in Battery :30000mA
Size :525*437*213mm
Weight:22kg
